Reckeen 3DSPRO Studio & LITE

Виртуальная студия Reckeen 3DSPRO Studio & LITE

Профессиональная виртуальная 3D телестудия с технологией SMARTKEY

• 4 x 3G SDI и 2 x 12G SDI входа
• 2 x HDMI 2.0 типа A с поддержкой 1080p60 до 4k 60p
• Карта синхронизации входов
• 8 x SDI выходов: 4 x SDI Chroma Key; 2 х PRV, 2 х PRG и HDMI
• Внешнее устройство Audio Digital Box ADB 100 для подключения по локальной сети к студии Reckeen 3D или LITE
• Панель управления VKey100 с джойстиком и T-bar
• Многокамерная система композиции 4x MultiCamera3D
• Изменение глубины резкости 4xDoF
• Функция 4 x Smartkey
• ПО:
  • Lite Production — виртуальная 2D студия
  • Still Editor — генератор титров и графики
  • VSM LITE EDITOR — редактор виртуального пространства
  • Кодер интернет вещания

Video input

• SDI Video Input
  • 4 x 3G – 3G/HD/SD auto switching
  • 3G,12G – 4 x 3G SDI and 2 x 12G SDI
• HDMI
  • 2 x HDMI 2.0 type A connector with support for 1080p60 up to 4k 60p

Monitor output

• 2 x DP output for monitor
• 2 x HDMI output for monitor – The number of HDMI/DP outputs depends on the graphics card

Audio input – ADB100

• Digital embedded stereo on each SDI and HDMI
• 2 x AES/EBU
• Analog
  • 4 x XLR two channels – professional balanced analogue audio stereo differential input (-10dBV, or 4dBu)
  • Two types of microphones – dynamic and condenser with + 48V phantom

Video output

• SDI Video Output
  • 8 x SDI – 3G/HD
  • 3G,12G – 6x3G/HD and 2x12G – 4k 60p
• HDMI
• HDMI 1.4 type A connector with support for 2160p30

I/O Port

• Tally Output
  • TL – DB26 – 4 channels
• Reckeen External Keyboard port
  • RS – DB9 – RS 232 and RS422
• Reckeen External Audio port
  • RJ45 – Audio Link
• Ethernet
  • Gigabit Ethernet LAN
• PC/2
  • PC keyboard
• USB
  • 2 x USB 3.0 ( front panel )
  • 4 x USB 3.0 ( back panel )
  • 1 x USB 3.1 ( back panel )

Audio output – ADB100

• Digital embedded stereo on each SDI and HDMI
  • 2 x AES/EBU
• Analog
  • 4 x XLR two channels – professional balanced analogue audio stereo differential input (-10dBV, or 4dBu)
  • 1 x Jack 6,3mm – stereo Headphone output

Video formats

• Reckeen SDI Virtual Studio System
  • Input
    • 2 x HDMI v1.4, 2x SDI
      • 2160p 30/25 on one HDMI
      • 1080p 60/59.94/50/30/29.97/25
      • 1080i 60/59.94/50
      • 720p 60/59.94/50
    • PAL, NTSC
  • Output
    • 2 x HDMI v1.4, 2x SDI
      • 2160p 30/25 on one HDMI
      • 1080p 60/59.94/50/30/29.97/25
      • 1080i 60/59.94/50
      • 720p 60/59.94/50
• Reckeen HDMI Virtual Studio System
  • Input
    • 4 x HDMI v1.4
      • 2160p 30/25 on two HDMI
      • 1080p 60/59.94/50/30/29.97/25
      • 1080i 60/59.94/50
      • 720p 60/59.94/50
    • PAL, NTSC
  • Output
    • 2 x HDMI v1.4
      • 2160p 30/25 on one HDMI
      • 1080p 60/59.94/50/30/29.97/25
      • 1080i 60/59.94/50
      • 720p 60/59.94/50

Reference input – (Genlock)

• Black Burst or Tri-Sync

Video standards

• SDI
  • Input – auto switching
    • 2 x SDI 12G 2160p 60/59.94/50/30/29.97/25
    • 6 x SDI 3G
      • 1080p 60/59.94/50/30/29.97/25
      • 1080i 60/59.94/50
      • 720p 60/59.94/50
      • PAL, NTSC
  • Output
    • 2 x SDI 12G 2160p 60/59.94/50/30/29.97/25
    • 6 x SDI 3G
      • 1080p 60/59.94/50/30/29.97/25
      • 1080i 60/59.94/50
      • 720p 60/59.94/50
      • PAL, NTSC
• HDMI
  • Input – auto switching
    • 2 x HDMI 2.0
      • 2160p 60/59.94/50/30/29.97/25
      • 1080p 60/59.94/50/30/29.97/25
      • 1080i 60/59.94/50
      • 720p 60/59.94/50
      • PAL, NTSC
  • Output
    • HDMI 1.4
      • 2160p 30/29.97/25
      • 1080p 60/59.94/50/30/29.97/25
      • 1080i 60/59.94/50
      • 720p 60/59.94/50

NDI

®

• NDI input:
  • 4 input interchangeably as cam 1 to cam 4 with supported stream key or Reckeen chroma key
  • 2 input interchangeably as media 1 and 2
• NDI output:
  • program out

© NDI® is a trademark of NewTek, Inc

Features

• Downstream Key – x2
• Media Format
  • MPEG2, MPEG4 and H.264 containers: (avi, mpg, mpeg, mp4, mxf, mov)
  • Audio: WAV, MP3
• Video Capture Format
  • H.264 (.mp4) MPEG-2 (.mpg)
  • 1080p 60/59.94/50/30/29.97/25
  • 1080i 60/59.94/50
  • 720p 60/59.94/50
  • H.264 up to 4k 30p and 60p
• Still Picture – x2 picture format .png, .jpg, .bmp
• Still Text – x2 Still Editor included
• Keyer – x4
  • Chroma Key / Luminance Key
  • SmartKey with 4 SDI outputs
• Streaming
  • Facebook
  • YouTube
  • NicoNico
  • NDI
  • and custom profiles

Software

• Reckeen Lite package:
  • Lite Production
  • VSM Lite Editor (also as a standalone version)
  • Still Editor
